Quick Details

  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: Horis
  • Model Number: HX8GF-HX1500GF
  • Output Type: AC Three Phase
  • Speed: 1500/1800
  • Frequency: 50/60Hz
  • Rated Power: 8KW-1500KW
  • Rated Voltage: 400/230V
  • Rated Current: 14.4-2700A
  • Engine: Cummins,Lovol,Deutz,Ricardo,Volvo,Styre,Wudong 135,138 .etc
  • number of cylinder: 2L,4L,6L,12V
  • noise level: 65dBA
  • regulator: AVR
  • start method: auto start
  • protection class: IP23
  • module: GU620A
  • function: ATS,AMF
  • control panel: digital
  • warranty: 18 months

Packaging & Delivery

Packaging Details Protection plastic + Plywood case,Export standard packing,
Delivery Time 10 days after the deposit



100KW stirling engine generator for sale,diesel generators



Product Description



1. Specification of genset
Gensets modelHX-100GF
Prime power100KW
Rated Voltage380/220V
Rated frequency(HZ)50
Rated Speed1500rpm
Power Factor0.8(lagging)
Dimensions(mm) (L×W×H)2600x 1000x1500
Net Weight(kg)1800
2. Specification of diesel engine
Engine brandYUCHAI
Engine modelYC6B155L-D21
Number of Cylinders6
Cylinder arrangementVertical in-line
CycleFour stroke
AspirationTurbocharged and Air/Air cooling
Fuel SystemDirect injection fuel pump
Bore×Stroke (mm×mm)108x 125
Displacement (Liter)6.87
Compression Ratio17.5:1
Speed GovernorElectronic
Cooling SystemForced Water Cooling Cycle
Total lubrication system capacity (L)17
Fuel Consumption at 100% Load (g/kwh)202
Starting MethodDC24V electrical starting
3. Specification of alternator
Alternator brandStamford
Alternator modelKH274C
Number of Phase3
Connecting Type3 Phase and 4 Wires
Number of Bearing1
Protection GradeIP21
Altitude1000m
Exciter TypeBrushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Insulation ClassH
Telephone Influence Factor (TIF)50
THF2%
Voltage Regulation, Steady State±1%
Transient State Voltage-15%~+20%
4. Specification of control Panel(with (with GU controller)
The control panel is AMF control panel, with the display of voltage,current, frequency, water temperature, oil pressure. The genset with low oil pressure,high water temperature,over speed,over load protection function.



Specification:



1) Yuchai series diesel engine



2) Alternator: Leroy Somer/ Stamford (brushless and self-exciting) with AVR



3) Output mode: Three phase four wire; Output Voltage: 110/220V , 220/380V, 230/400 V



4) Frenquency: 50HZ/60HZ; Power factor: 0.8;



5) Steady State Voltage regulation:±1%; Insulation class: H; Protection:IP21 to 23



6) 8 hours running basefuel tank as STD, 12 hours base fuel tank for option



7) Control Panel: Key Start / Key& Auto Start / Auto Start / AMF / Emergency Stop button



8) Accessories: Battery, Battery cable, flexible bellows& flanges, industrial exhaust silencer, tool kit, etc



Packaging & Shipping

1. Standard plywood case, its compressive strength and bearing quality is better.

2. the board area is bit, the soil structure is good,  it is better in leakproofness and waterproof.

3.when importing, the plywood case is with fumigation-free, the procedure is simple.



Our Services

After sales service:

1. 18 months guarantee of the whole machine,We will provide the consumable parts at an agency price when you need replacement.

2. Our engineer could support you technology to your contry  if  necessary.

3. Our enginner could service on weekend even on vacation.

4. Our engineer could train you on at our factory for free.

5. Our engineer could service you 24 hours online by skype, yahoo, msn, QQ, or by cellphone.



Company Information
We custom build, maintain and supply diesel and gas generators to suit your needs. Whether for continuous use or to kick-in when a power cut hits, to be silent, trailer mounted, stabilised… whatever your business needs! We also offer comprehensive maintenance and an invaluable Load Testing service to keep your standby generator in peak condition.
Please browse our site, but don’t hesitate to pick up the phone and call us. We’ve installed our systems on a wide range of sites – so your needs may already be familiar.

FAQ

How does a generator set work with the mains electricity supply?

Constant mains electricity is supplied into premises via electrical cabling. When this mains electricity is

 disrupted due to power failures, a signal is sent from the transfer switch to the generator set which then

 starts up the generator and when the electrical supply from it is stable, sends generated electricity back

 into the premises. When the mains supply is restored and stable the transfer switch reverts back to the

 mains and sends a signal to the generator to go back into standby mode.

How long will a generator run on its internal tank of fuel?

The amount of time that a generator will run on a tank of fuel depends on the size of the tank and the

 load required from the generator. Each of our generators comes with a minimum of 9 hours (unless

stated otherwise) run time at maximum load. With an external fuel tank, this run time can be extended

even further.

What is kVA and is it the same as kW?

No. kVA stands for Kilo Volt Amperes and is the true power produced by a generator. kW (or kilowatts) is the

actual power that is used.

How do I know what size of generator set to purchase for my premises?

HorisPower can conduct a site survey to ascertain your requirements. We conduct an electrical usage survey

 over a fix period of time using the latest diagnostic tools. The information gathered is then prepared and a

 report produced. This information provides you with information you require to correctly size your generator.
